    CNC DOVETAIL MACHINE 6600S

    Page info

    Writer Admin Date16-03-11 13:06 Hit885 Comment0

    Contents

    MODEL 6600
    Machine size 1700mm x 1060mm x 1300mm
    Weight 700kg
    Electric 3ph/220v/5kw
    Working table size 1700mm x 610mm
    Working height (thickness) 150mm
    Working width 1150mm
    Spindle speed 18,000rpm
    Auto fence system -
    Clamp separated 2position
    2 position working each section working
    max working width 550mm
    1 cycle Auto system width Foot switch -
    Foot switch 2units -
    Spindle motor 2.2kw
    Touch screen 7" TFT LCD
